Rake Back Double Channel Stair Nosing 2.44m, 2.75m 85mm Tread


Price
Sale price £198.90 (Inc. VAT)
➜ Need help? Call us on 01282 270 010

In stock, ready to ship

Description

Rake Back Double Channel Aluminium Stair Nosing

A precision-engineered, double channel rake back stair nosing manufactured from extruded aluminium, designed to protect and define the leading edge of stair treads. Fitted with two slip-resistant PVC inserts, this profile delivers reliable underfoot safety on internal staircases in residential, commercial, and public-access environments. Available in two stock lengths — 2.44m and 2.75m — with a broad selection of aluminium finishes and insert colours to suit any interior scheme.

Product Specifications

Profile Material Extruded Aluminium
Insert Material Slip-Resistant PVC
No. of Insert Channels 2 (Double Channel)
Stair Profile Requirement Rake Back (Angled Underside)
Suitable Floor Coverings Vinyl, Lino, Lightweight Carpet
Stock Lengths 2.44m (2440mm) & 2.75m (2750mm)
Tread (Horizontal Width) 85mm
Riser Rake Back Profile — angled to sit flush against the riser face
Gauge (Material Thickness) 3.5mm
Insert Type Slip-Resistant PVC Insert
Fixing Method Screw Fixed (countersunk fixing holes along tread)
Application Internal Staircases — Residential, Commercial & Public Access

Aluminium Finishes

Mill Finish
Bright Polished
Satin Black
Satin Gold
Dark Bronze
Mirrorflect Gold

Insert Colours

Premium Black
Mid Grey
Dark Grey
White
Beige
Sahara
Brown
Red
Dark Blue
Dark Green
Sage Green
Apple Green
Yellow
Hazard
Aura
Insert colours are selected at the point of order. For staircases requiring high-visibility demarcation, Hazard and Yellow inserts provide strong contrast against the tread surface.

Key Features

  • Double channel profile accommodates two PVC inserts for enhanced slip resistance across the full tread width
  • Rake back underside profile designed to sit flush and secure against the angled riser face of the stair
  • 3.5mm gauge aluminium construction provides a robust, long-lasting edge protection solution
  • 85mm tread width offers generous coverage of the stair leading edge
  • Available in 2.44m and 2.75m stock lengths — suitable for standard and wider stair configurations
  • Six aluminium finishes available, from understated Mill Finish to decorative Mirrorflect Gold
  • Fifteen insert colour options allow precise visual contrast or tonal coordination with surrounding flooring
  • Screw-fixed installation method ensures a secure, permanent fit on internal staircases
  • Compatible with vinyl, lino, and lightweight carpet floor coverings
  • Suitable for residential, commercial, and public-access internal staircase applications

Application & Installation Guidance

This profile is designed exclusively for internal staircases where the riser face is angled — a configuration commonly referred to as a rake back stair. The angled underside of the nosing sits flush against the riser, eliminating gaps and ensuring a clean, professional finish at the stair edge.

The double channel format accepts two PVC inserts, which are pressed into the extruded channels after the aluminium body has been fixed in position. Inserts can be cut to length using a fine-tooth saw or sharp utility knife. The profile is fixed using countersunk screws through the tread face; pilot holes should be pre-drilled to prevent the aluminium from splitting.

This nosing is suitable for use over vinyl, lino, and lightweight carpet. It is not recommended for use over thick or heavily cushioned carpet, stone, or tile without prior assessment of the substrate and fixing method.

Frequently Asked Questions

What does “rake back” mean and how do I know if my stairs require it?

A rake back profile has an angled underside that follows the slope of the riser face on certain stair constructions. If the face of your riser is angled rather than vertical, a rake back nosing is required to achieve a flush, gap-free fit. Standard (bullnose) nosings are designed for vertical risers only.

Can this nosing be cut to a shorter length on site?

Yes. Both the 2.44m and 2.75m lengths can be cut to size using a mitre saw or fine-tooth hacksaw fitted with a blade suitable for non-ferrous metals. Always deburr cut ends before installation to ensure a clean, safe finish.

Are the PVC inserts replaceable after installation?

Yes. The inserts sit within the extruded channels and can be removed and replaced without disturbing the fixed aluminium body. This makes it straightforward to refresh worn inserts or change the insert colour at a later date.

Is this profile suitable for external or wet-area staircases?

No. This profile is designed for internal use only. For external staircases or areas subject to standing water, a profile with an exterior-grade insert and appropriate drainage consideration should be selected instead.

Delivery Information

ServiceTimeframeCost
Standard UK Delivery2–4 business days£9.99

Orders placed before 12pm Mon–Fri are typically dispatched same day. Delivery to all UK addresses. Contact us for international enquiries.

Payment & Security

American Express Apple Pay Diners Club Discover Google Pay Klarna Maestro Mastercard Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

You may also like

Recently viewed

Frequently Asked Questions

Find answers to common questions about our stair nosings

Stair nosings are protective edge strips fitted to the front of stair treads. They serve multiple purposes: preventing slip accidents, protecting stairs from wear, meeting building regulations, and improving visibility for those with impaired vision. They're essential for both safety compliance and extending the life of your stairs.

Yes, all our products are designed to meet UK Building Regulations, including:

  • Part K – Protection from falling and collision
  • Part M – Access to and use of buildings
  • BS 8300 – Design for disabled access

Our contrasting nosings meet the requirements for visually impaired users.

We offer stair nosings in multiple materials:

  • Aluminium – Lightweight, durable, ideal for most applications
  • GRP/Fibreglass – Heavy-duty, excellent for external and industrial use
  • Rubber/PVC – Flexible, great for refurbishment projects
  • Brass – Premium finish for high-end residential

Yes! We offer a cut-to-length service for most of our stair nosing products. Simply provide the measurements you need when ordering, or contact our team for assistance. This ensures a perfect fit with minimal on-site cutting required.

Installation varies by product type but typically involves:

  • Screw-fixed – Drill, countersink and screw into substrate
  • Adhesive-fixed – Use high-strength adhesive for bonding
  • Channel systems – Insert nosing into pre-installed track

We provide detailed PDF installation guides and video tutorials for every product range.

We offer fast UK delivery on all orders:

  • Standard Delivery – 2-3 working days
  • Express Delivery – Next working day (order before 2pm)
  • Free Delivery – On orders over £100

Large or bulk orders may require pallet delivery – contact us for details.

Yes, we offer trade accounts for contractors, architects, and facilities managers. Benefits include:

  • Competitive bulk pricing
  • 30-day payment terms (subject to approval)
  • Dedicated account manager
  • Priority technical support

Contact us to apply for a trade account.

Ramp/Angled – Gradual slope, best for high-traffic areas and wheelchair access
Bullnose/Round – Curved edge, traditional look, good for residential stairs
Pencil Edge – Minimal profile, sleek modern appearance

Choose based on your aesthetic preference and the level of protection required.
